3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System

Tianjin Ejon Flying Science And Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System from wholesalers

    Buy cheap 3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System from wholesalers
    • Buy cheap 3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System from wholesalers
    • Buy cheap 3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System from wholesalers
    • Buy cheap 3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System from wholesalers
    • Buy cheap 3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System from wholesalers
    • Buy cheap 3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System from wholesalers
    • Buy cheap 3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System from wholesalers

    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System

    Ask Lasest Price
    Brand Name : Ejon
    Supply Ability : 5000 Set/Sets per Year
    Price : $12,100.00/sets 1-2 sets
    • Product Details
    • Company Profile

    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System

    Product Overview

    Ejon S13 3d channel sign machine outdoor stainless steel sign backlit led machine
    sign channel letter equipment
    бортогибочный станок для букв,ماكينة الانحناء للحروف,dobladora de letras de canal,dobladora de letras 3d
    Ejon S13 Multifunctional Automatic Channel Letter Bending Machine is widely used in advertising company for metal signs manufacturing, including seiko letters, resin letters, narrow edge letters, rimless letters, luminous letters, etc. and is very popular in Middle East, America and Russia, etc. The using of full servo motor ensures the accuracy and stability of feeding, slotting, heightening and bending. Small radian bender can be customized, the minimum angle can reach to R3. It is the first choice for high-end LED characters, aluminum profile letters, stainless steel letters, punched letters, resin letters and other sign letters.

    Main characteristic of hardware

    1. Double ball screw matched with nylon gear transmission.
    2. Slotting mechanism with air blowing and cooling function.
    3. Feeding support controlled by air cylinder.
    4. High strength alloy planer controlled by high power servo.
    5. Ductile cast iron double blades bending structure.
    6. Steel coupling plus specially treated bender.
    7. Extra long bending span(20 cm longer than before).

    Main characteristic of software

    1. Various processing methods can be switched at will for different materials and fonts. 2. The injection amount can be accurately calculated according to the injection process. 3. The software integrates material data of the plates to ensure the bending degree. 4. The software automatically optimizes nodes, without the need for customers to manually delete nodes. 5. One click to switch the use of different cutters for different materials.
    6. Plate data is automatically saved without multiple adjustments. 7. Continuous processing mode can be selected for batch processing, which is convenient and fast. 8. For angles smaller than R6, the thinning function can be selected to meet the requirements of various fonts. 9. Default sharp angle slotting function ensures the matching degree of slotting angle.
    FEATURES AT A GLANCE
    As a production equipment specializing in the processing of stainless steel seiko characters on the market, S13 can accurately fold out the edge, and realize the high-precision embedding of the letter face and the bottom plate, which greatly improves the appearance and three-dimensional sense of the luminous characters.
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    Cast clamps can avoid scratching the material, meanwhile improving the feeding holding.
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    The encoder monitors the numerical change of the feeding length in real time, compensates the unqualified data, and ensures the feeding accuracy.
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    Equipped with 4-axis high-power 750W full servo control system to ensure the accuracy and stability of feeding, slotting, heightening and bending.
    PRODUCT SPECIFICATIONS
    No
    Item
    Data
    1
    Power
    AC220V, 50Hz, 2.0 kW
    2
    Material thickness
    0.4~1.2 mm
    3
    Slotting trip
    Planer cutter: 10~130 mm; Milling cutter: 20~100 mm
    4
    Applicable material
    Metal sheet: stainless steel, galvanized plate, aluminum plate, iron
    Aluminum profile
    5
    Control system
    4 axis servo control system
    6
    Slotting method
    Plane cutter/Milling cutter
    7
    Package size
    1410 mm * 750 mm * 1560 mm;
    660 mm *660 mm * 1110 mm
    8
    File format
    Dxf.Plt.Ai
    9
    Machine weight
    500 kg
    Sample Letters Show
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    Seiko letter
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    Resin letters
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    Narrow edge letters
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    Rimless letter
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    Luminous letters
    3D Metal Letter Bending Machine S13 With Double Blade Alternate Bending System
    Luminous letters
